HRC65 Carbide Ball Nose End Mill Bullnose 4 Flute Nano Coating

Product Categories

Shenzhen Bwin Precision Tools Co., Ltd.

Contact Now

HRC65 Carbide Ball Nose End Mill Bullnose 4 Flute Nano Coating

Ask Lasest Price
Brand Name :	BWIN
Model Number :	*R832d16100L**
Price :	Negotiable
Payment Terms :	T/T, Western Union
Supply Ability :	1-10000pcs 7days
Delivery Time :	7 work days

Add to Cart

Product Details
Company Profile

HRC65 Carbide Ball Nose End Mill Bullnose 4 Flute Nano Coating

HRC65 4 Flute Solid Carbide Milling Cutter Ball Nose End Mill Ballnose Bullnose Endmills

Characteristic:

Preferred raw materials
imported equipment
The blade passes the center
Nano coating
Shank chamfer

Description:

The 65 degree universal ball nose end mill made of 0.2UM fine grain high-quality tungsten steel base material has higher wear resistance and hardness, sufficient toughness and wear resistance, and is more durable; High precision grinding technology of imported Walter grinder, not easy to wear, long service life; The knife edge is passivated to reduce burrs and cracks during sawtooth processing, enhance the wear resistance of ball nose end milling cutter and improve the surface finish; The handle chamfer design is easy to clamp and more firm.

Milling Parameters:

HRC45 Carbide End Mill				Tool length		fz&v
				Short		1
				Long1		0.9
				Overlength		0.8
				Speciality		0.6
Type			Material	Strength N/mm² Hardness HRC	Cooling



					Air	Dry cutting	Lubricating fluid
P	PI	P1.1	Non alloy structural steel, free cutting structural steel, carburized steel and quenched and tempered steel	<700	√	√	√
	PI	P1.2	quenched and tempered steel	<1200	√	√	√
	P2	P2.1	Alloyed nitrided steel, carburized steel and quenched and tempered steel	<900	√	√	√
	P2	P2.2	Tool steel, bearing steel, spring steel and high-speed steel	<1400	√		√
	P3	P3.1	Tool steel, bearing steel, spring steel and high-speed steel	<900	√	√	√
	P3	P3.2	Tool steel, bearing steel, spring steel and high-speed steel	<1500	√		√
M	M1	M1.1	austenitic stainless steel	＜700	√		√
	M1	M1.2	Ferritic/austenitic (bicrystal) stainless steel	＜1000			√
	M2	M2.1	Austenitic stainless cast steel	＜700	√		√
	M3	M3.1	Ferritic/austenitic (bicrystal) stainless cast steel	＜1000			√
K	K1	K1.1	Flake graphite cast iron (gray cast iron), GJL	＜300	√	√	√
	K2	K2.1	Ductile iron, GJS	＜500	√	√	√
		K2.2	Ductile iron, GJS	500-800	√	√	√
		K2.3	Ductile iron, GJS	＞800	√	√	√
	K3	K3.1	Vermicular graphite cast iron, GJV; Malleable cast iron, GJM	＜500	√	√	√
	K3	K3.2	Vermicular graphite cast iron, GJV; Malleable cast iron, GJM	＞500	√	√	√
H	H1	H1.1	Hardened steel/cast steel	45-55	√	√	√
	H1	H1.2	Hardened steel/cast steel	55-64	√	√	√
	H2	H2.1	Wear resistant cast iron/chilled cast iron, GJN		√		√

Finish
Vc (m/min)				fz(mm/tooth)
				Diameter
				2	4	6	8	10	12	14	16	18	20
P	P1	P1.1	332	0.028	0.05	0.07	0.091	0.11	0.128	0.144	0.16	0.173	0.186
	P1	P1.2	272	0.026	0.046	0.066	0.085	0.103	0.12	0.135	0.15	0.162	0.173
	P2	P2.1	304	0.028	0.05	0.07	0.091	0.11	0.128	0.144	0.16	0.173	0.186
	P2	P2.2	212	0.023	0.041	0.059	0.076	0.092	0.107	0.121	0.134	0.145	0.155
	P3	P3.1	196	0.027	0.047	0.067	0.086	0.104	0.122	0.137	0.152	0.165	0.177
	P3	P3.2	168	0.024	0.043	0.061	0.079	0.095	0.111	0.125	0.139	0.150	0.161
	P4	P4.1	136	0.019	0.033	0.047	0.06	0.073	0.085	0.096	0.107	0.116	0.124
	P5	P5.1	204	0.027	0.048	0.068	0.088	0.106	0.124	0.140	0.155	0.168	0.18
	P6	P6.1	136	0.013	0.023	0.033	0.042	0.051	0.06	0.068	0.075	0.081	0.087
M	M1	M1.1	92	0.016	0.029	0.041	0.053	0.064	0.075	0.0845	0.094	0.101	0.108
	M1	M1.2	84	0.014	0.024	0.034	0.044	0.053	0.062	0.0695	0.077	0.0835	0.09
	M2	M2.1	100	0.018	0.031	0.045	0.057	0.07	0.081	0.0915	0.102	0.11	0.118
	M3	M3.1	92	0.014	0.025	0.035	0.045	0.055	0.064	0.072	0.08	0.0865	0.093
K	K1	K1.1	364	0.047	0.083	0.117	0.151	0.183	0.214	0.2405	0.267	0.149	0.031
	K2	K2.1	332	0.04	0.07	0.1	0.128	0.156	0.182	0.2045	0.227	0.245	0.263
		K2.2	272	0.033	0.058	0.082	0.106	0.128	0.149	0.168	0.187	0.202	0.217
		K2.3	152	0.019	0.033	0.047	0.06	0.073	0.085	0.096	0.107	0.1155	0.124
	K3	K3.1	240	0.033	0.058	0.082	0.106	0.128	0.149	0.168	0.187	0.202	0.217
	K3	K3.2	228	0.028	0.05	0.07	0.091	0.011	0.128	0.144	0.16	0.173	0.186
H	H1	H1.1	92		0.021	0.029	0.038	0.046	0.053	0.06	0.067	0.072	0.077
	H1	H1.2
	H2	H2.1

Note:

If the following carbide end mill cannot meet your requirements, we support OEM customized production. The diameter of 0.2mm to 25mm, the total length of 50mm to 200mm, 4F, 5F, 6F, 8F and logo can be customized, including inch size end milling cutter. Please contact us to select or customize non-standard carbide end mill according to your needs.

Specification	Flute Radius	Flute Length (C)	Shank Radius	Overall Length(L)
R0.52d4*50L	0.5	2	4	50
R0.753d4*50L	0.75	3	4	50
R14d4*50L	1	4	4	50
R1.255d4*50L	1.25	5	4	50
R1.56d4*50L	1.5	6	4	50
R1.757d4*50L	1.75	7	4	50
R28d4*50L	2	8	4	50
R2.510d5*50L	2.5	10	5	50
R312d6*50L	3	12	6	50
R416d8*60L	4	16	8	60
R520d10*75L	5	20	10	75
R624d12*100L	6	24	12	100
R728d14*150L	7	28	14	150
R832d16*100L	8	32	16	100
R936d18*100L	9	36	18	100
R1040d20*100L	10	40	20	100

Instructions:

1. Before using the carbide end mill, please measure the tool deflection. If the tool deflection accuracy exceeds 0.01mm, please correct it before cutting.

2. The shorter the carbide e extends out of the collet, the better. If the tool extends out longer, reduce the speed, feed speed or cutting amount.

3. In case of abnormal vibration or sound during cutting, please reduce the speed and cutting amount until the situation is improved.

4. Spray type and air jet type are preferred for steel cooling, which can improve the use effect of carbide end mill.

5. Note: Not suitable for low speed machines such as rotary table and electric hand drill.

Applications:

Pre-hardened Steel, stainless steel, Die steel, steel plate, Heat-resistant steel,pipe, copper and aluminum, cast iron, Nonferrous Metal, Wood, Plastic,FRP and sO on. General-purpose operation slotting, rilling, profiling.

Cnc Milling Cutter 6mm 3 4 Flute Tungsten Solid Carbide High Feed Endmill End Mill

FAQ

Q1: The surface of the workpiece is glossy, but the concavity and convexity are large

resolvent:

(1) Reduce the feed.

(2) The low number of cutting edges changes the high number of cutting edges to improve the surface fineness.

Q2: The chip is short and thin, but there are sticky chips

resolvent:

(1) Increase cutting speed.

(2) Change to wet type (using cutting fluid), and use it with vortex tube gun to reduce the tool temperature and avoid overheating.

(3) Perform minor rounding and passivation treatment.

(4) Change from up milling to down milling.

(5) Increase the feed rate or the cutting allowance.

Q3: There are transverse cuts

resolvent:

(1) Perform minor rounding and passivation treatment.

(2) Use water-insoluble cutting fluid.

(3) Change from forward milling to reverse milling.

Q4:The finishing size is too small

resolvent:

(1) Change from up milling to down milling.

(2) Reduce the cutting allowance.

(3) Replace the chuck or spring collet.

(4) Reduce the cutting depth of the end mill.

(5) Increase cutting speed.
